AMITI21-AC TYPE
Product Introduction:
The AMITI21 charging pile is an AC charging pile for home use and can also be delivered by vehicle, rated power of 7 ~ 22kW. It supports Type1, Type2, GB/T. The design of the product is simple and lightweight. It can be used in two ways: wall box and floor stand. The product protection level is IP54, and the standby power consumption is less than 2W.
Product Features:
Easy to install, can be installed anywhere.
Real-time fault monitor, remote diagnosis, OTA upgrade.
Humanized operation, supports various mobile payment methods.
Comprehensive electrical protection.
High quality, obtained multiple certifications for TUV and CE.
Usage scenario:
- Office
- Shopping Mall
- Charging Station
- Family Garage
5-inch Large Screen
LCD Touch Screen
Overload/leakage protection
Protection Level
Anti-UV Protection
RFID Card Reader
Better View
A Better view at our AMITI21-AC TYPE
High speed charging capabilites
The AMITI21 Charger is capable of charging electric vehicles quickly and efficiently, reducing charging time and maximizing convenience for users.
Versatility
With the built-in hybrid plug-ins, the EV charger is compatible with a wide range of EV cars. The feature makes this charger versatile for every EV owner.
Smart App Control
Our advanced and user-friendly app can control the EV charger remotely, including schedule charging, charging ratio, nearby station, etc.
Safety features
Some safety measures like sturdy wire, overvoltage protection, power indication, etc. are included with this EV charger.
Intelligent Monitoring
The AMITI21 has an intelligent monitoring feature, enabling it to analyze and monitor charging progress, real-time data, battery health, etc.
Durable & Robust Design
The EV charger is built strong, and it can easily handle harsh weather conditions, which makes it long-lasting and durable.
Easy to Use
The charger comes with a user-friendly interface and functionality, making the EV charger more convenient to install and operate.
Cost-effective
The AMITI52 has a minimal power consumption rate and provides cost-effective benefits to users in the long run.
Technical Data
Technical Data
Configurations
Basic
Outlet :
Output Power
Single
7kW/11kW/22kW
Dimensions
Weight :
H*W*T :
3kg (without cable)
350mm*196mm*150mm
General Specifications
Appearance
Shell Material :
Dimensions :
Installation Type :
Weight :
Cable Length :
ABS
H×350mm | W×196mm | D×150mm
Wall Mounted, Floor Stand (Optional)
3kg (Without Cable)
≥4.2m (External Line)
Electrical Features
Input Voltage :
Charging Socket :
Output Rating :
| Single Phase: 230VAC±10% Single (Type 2) Three Phase: 400VAC±10% 7KW/11KW (Single Phase) 22KW (Three Phase) |
Output Current :
Input Frequency :
Precision :
Standby Power :
32A
50Hz/60Hz
Class 1
<2w
Functional Features
Earth Leakage Protection :
User Interface :
Safety Features :
Type B 30mA AC and 6mA DC
Emergency Stop Button, LED Indicator,
LCD Touch Screen, RFID
Overvoltage Protection, Over Current Protection,
Leakage Protection
Communication
Network Interface :
OCPP :
Ethernet (Wi-Fi, 3G/4G, LTE as option)
OCPP1.6J
Working Environment
Application Place :
Working Temperature :
Working Humidity :
Working Altitude :
Protection Grade :
Cooling :
Special Protection :
Indoor/Outdoor
-30°C to +55°C
5% to 95%
<2000m
IP54
Natural Cooling
Anti-UV Protection
